Writeup DGA - CTF - Bwing
This article describes my solution for the 150-point challenge called “Bwing”.
Introduction
Un expert forensic de DGA MI doit travailler sur un dump mémoire.
Au profit de l’activité missile, il doit retrouver des informations au sujet du plan d’une fusée.
Start
We have a file that once decompressed doesn’t give us much information about what type of file it is.
file dump.raw
dump.raw: data
However we know that it is a memory image. The tool of choice to use is Volatility. Before we can use this tool on our memory image we need to generate a profile. I won’t go into the details of what a profile is because this is not the purpose of this article.
To generate a profile you need to know the GNU/Linux distribution and the kernel version to have the right memory mapping (among others).
Profile’s generation
As said before, we need to identify the GNU/Linux distribution as well as the kernel version.
strings dump.raw | grep -i "distrib_description="
DISTRIB_DESCRIPTION="Ubuntu 18.04.3 LTS"
Now let’s identify the kernel version.
strings dump.raw | grep -i "linux version"
Linux version 4.15.0-66-generic (buildd@lgw01-amd64-044) (gcc version 7.4.0 (Ubuntu 7.4.0-1ubuntu1~18.04.1)) #75-Ubuntu SMP Tue Oct 1 05:24:09 UTC 2019 (Ubuntu 4.15.0-66.75-generic 4.15.18)
So I can tell that it is an Ubuntu 18.04.3 LTS with kernel 4.15.0-66-generic downloadable here.
Once the installation of Ubuntu is done in a virtual machine, the only thing left to do is to generate the profile.
Check the kernel version
uname -r
4.15.0-55-generic
It is necessary to install the correspondent kernel, it can be installed like follows. Make sure to reboot to load the last version at boot.
Install a new kernel
sudo apt install linux-image-4.15.0-66-generic
sudo reboot
Check the kernel a new time.
uname -r
4.15.0-66-generic
We are good to go.
Install required utilities
sudo apt install dwarfdump build-essential libelf-dev zip
Clone the Volatility repositories
git clone https://github.com/volatilityfoundation/volatility.git
Generate the profile
cd volatility/tools/linux
make
Zip all the things
sudo zip $(lsb_release -i -s)_$(uname -r)_profile.zip module.dwarf /boot/System.map-$(uname -r)
Once it is done, you end up with the following file.
file Ubuntu_4.15.0-66-generic_profile.zip
Ubuntu_4.15.0-66-generic_profile.zip: Zip archive data, at least v2.0 to extract
I then retrieved this file on my computer, created a virtual environment, cloned the volatility repository and placed this file in zip format in volatility/volatility/plugins/overlays/linux/.
virtualenv2 bwing
cd bwing
source bin/activate.fish
(bwing) git clone https://github.com/volatilityfoundation/volatility.git
(bwing) mv ~/Ubuntu_4.15.0-66-generic_profile.zip volatility/volatility/plugins/overlays/linux/
(bwing) mv ~/dump.raw .
(bwing) cd volatility/
Some Python modules are required to execute Volatility correctly.
(bwing) pip install distorm3 Crypto pycrypto
Now, we can see if everything is ready to work by executing the following command.
(bwing) python vol.py --info | grep Ubuntu
Volatility Foundation Volatility Framework 2.6.1
LinuxUbuntu_4_15_0-66-generic_profilex64 - A Profile for Linux Ubuntu_4.15.0-66-generic_profile x64
Our profile is detected!
Forensic analysis
Now we have everything we need to conduct our forensic analysis. We need to proceed in this way in order, for example, to display the processes running while the memory capture was in progress.
(bwing) python vol.py -f ../dump.raw --profile=LinuxUbuntu_4_15_0-66-generic_profilex64 linux_pslist
Volatility Foundation Volatility Framework 2.6.1
Offset Name Pid PPid Uid Gid DTB Start Time
------------------ -------------------- --------------- --------------- --------------- ------ ------------------ ----------
0xffff95a89f22ad80 systemd 1 0 0 0 0x000000001c994000 2019-11-06 09:46:55 UTC+0000
0xffff95a89f2296c0 kthreadd 2 0 0 0 ------------------ 2019-11-06 09:46:55 UTC+0000
0xffff95a89f22db00 kworker/0:0 3 2 0 0 ------------------ 2019-11-06 09:46:55 UTC+0000
0xffff95a89f228000 kworker/0:0H 4 2 0 0 ------------------ 2019-11-06 09:46:55 UTC+0000
[...]
A very interesting module named linux_recover_filesystem allows to recover the whole filesystem. I use this plugin with the -D flag to specify the directory where the filesystem should be stored. For some reason I don’t know, if I don’t execute this command with sudo, I have a rights error.
(bwing) mkdir filesystem
(bwing) sudo python vol.py -f ../dump.raw --profile=LinuxUbuntu_4_15_0-66-generic_profilex64 linux_recover_filesystem -D filesystem
[...]
Recovered 14394 files
Modify rights.
(bwing) sudo chown -R $USER:users filesystem/
As usual as soon as I have a filesystem I look for all occurrences of the word flag.
(bwing) grep -R "flag" filesystem/
[...]
filesystem/tmp/vagrant-shell:sudo cp /vagrant/flag.txt /mnt/confidential/flag.txt
filesystem/tmp/vagrant-shell:cat /mnt/confidential/flag.txt
[...]
The /mnt/confidential/flag.txt file seems to be very interesting!
(bwing) cat filesystem/mnt/confidential/flag.txt
C0D3N4M34P011011
This is the flag to validate this challenge.
